EZVIZ CS-CP1 3MP 2K Smart Wi-Fi Pan & Tilt Camera
Free Delivery
Free delivery on orders over R600 within Pretoria
CP1 3MP
See clearer and wider.
Smart Wi-Fi Pan & Tilt Camera.
Watch over your entire space easily with the CP1 Camera’s 360-degree field-of-view and its smart tracking feature. It’s got you covered – all day & all night.
2K Resolution
Smart Night Vision(up to 10m / 33ft.)
Motorized Pan and Tilt for 360° Visual Coverage
Two-Way Talk
Smart Tracking
Sleep Mode for Privacy Protection
H.265 Video Technology
View from Anywhere
MicroSD Slot(up to 256 GB)
Motion Detection
Wi-Fi 2.4 GHz
See everything clearly in 3MP resolution.
This camera can record video in 3MP resolution, which offers more details than 2MP cameras.
2MP
3MP
Zero blind spots.
Keep tabs on every corner with just one CP1. Its expansive 360-degree field-of-view ensures full coverage, so you don’t miss a thing.
Vertical rotation
Horizontal rotation
55°
350°
Smart tracking.
When it detects a moving object, the CP1 is smart enough to automatically track its motion while alerting you with an image in real-time.
Communication, anytime.
Talk to your loved ones and deter unwelcome strangers – all by using the CP1’s two-way communication feature. Using the EZVIZ App on your mobile device, you can easily and conveniently enjoy communication wherever you might be.
See further in the dark.
Enjoy round-the-clock protection with the CP1 camera. Using powerful Infrared LED lights, it lets you see up to 10 meters (33 feet) in dim light.
We protect your data and privacy.
Protecting your data and privacy is our highest priority. Data transmission between the camera and the EZVIZ Cloud is encrypted from end to end. Only you have the keys to decrypt your data. To get an extra layer of privacy protection, you can always enable the camera’s sleep mode on the EZVIZ App.
AES 128-bitencryption
TLS encryption Protocol
Multiple authentication steps
Specifications| Specifications | |
|---|---|
| Model | CS-CP1-A0-2C3WF |
| Camera | |
| Image sensor | F2.0@1/2.7" Progressive Scan CMOS |
| Shutter Speed | Self-adaptive shutter |
| Lens | 4mm, view angle: 104°(Diagonal), 85° (Horizontal), 55°(Vertical) |
| Lens Mount | M12 |
| Day & Night | IR-cut filter with auto-switching |
| DNR | 3D DNR |
| WDR | Digital WDR |
| Compression | |
| Video Compression | H.265 / H.264 |
| Video Bit Rate | Quad HD, Full HD, HD, Standard. Adaptive bit rate. |
| image | |
| Max. Resolution | 2304 × 1296 |
| Frame Rate | Max. 20 fps; Self-Adaptive during network transmission |
| Network | |
| Smart Alarm | Motion detection |
| Wi-Fi Pairing | AP pairing |
| Protocol | EZVIZ cloud proprietary protocol |
| Interface Protocol | EZVIZ cloud proprietary protocol |
| Interface | |
| Storage | Micro SD card slot (Max. 256G) |
| Power | Micro USB |
| Wired Network | RJ45 × 1 (10M/100M self-adaptive Ethernet port) |
| Wi-Fi | |
| Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20MHz |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate | 11b: 11Mbps, 11g :54Mbps, 11n :72Mbps |
| Output Power(EIRP) | 19 dBm |
| Antenna Gain | 1.9 dBi |
| General | |
| Operating Conditions | -10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing) |
| Power Supply | DC 5V/1A |
| Power Consumption | Max. 5W |
| IR Range | Max. 10 m (32.81 ft) |
| Dimensions | 88 × 88 × 119 mm (3.46 × 3.46 × 4.69 inch) |
| Packaging Dimensions | 103 × 103 × 186 mm (4.06 × 4.06 × 7.32 inch) |
| Bare Weight | 218g (7.69 oz) |
| In the box: | |
| In the box: | - CP1 Camera |
| - Base | |
| - Screw Kit | |
| - Power Cable 3m (9.8 ft.) | |
| - Drill Template | |
| - Power Adapter | |
| - Quick Start Guide | |
| - Regulatory Information | |
